Parameter
|
ADD
channel
|
DROP
channel
|
ADD
channel
|
DROP
channel
|
|
Center
Wavelength(nm)
|
1550nm
Window,. ITU Grid
|
|
Center Wavelength
Accuracy (nm)
|
≦0.1
|
|
Channel Spacing (Ghz)
|
100
|
200
|
|
Channel Passband (nm)
|
ITU
±
0.11
|
ITU
±
0.25
|
|
Add/Drop Insertion
Loss (dB)
|
≦1.5
|
≦1.5
|
|
Express Channel
Insertion Loss (dB)
|
≦1.0
|
≦1.0
|
|
Add/Drop Channel
Ripple (dB)
|
≦0.3
|
≦0.3
|
|
Express Channel
Insertion (dB)
|
≧24
|
≧24
|
|
CAdjacent
Channel Isolation@Add/Drop path (dB)
|
≧15
≧30
|
≧15
≧30
|
|
Non-Adjacent
Channel Isolation@Add/Drop path (dB)
|
≧15
≧35
|
≧15
≧35
|
|
Insertion Loss Temperature
Sensitivity (dB/℃)
|
≦0.005
|
|
Wavelength Temperature
Sensitivity (nm/℃)
|
≦0.002
|
|
Reture Loss (dB)
|
≧45
|
|
Directivity (dB)
|
≧55
|
|
Polarization Dependent
Loss
(PDL) (dB)
|
≦0.2
|
≦0.15
|
|
Polarization Mode
Dispersion (ps)
|
≦0.1
|
≦0.1
|
|
Maxmum Power
Handling (mW)
|
300
|
|
Maximum Temsild Load(N)
|
5
|
|
Operating Temperature(℃)
|
-20
to 70
|
|
Storage Temperature(℃)
|
-40
to 85
|
|
Package Dimension (nm)
|
125(L)
×
90(W) × 8(H)
|
|
Values
are referenced without connector(s)
|
